We serve the P grade and K grade micro fine grain solid carbide basic materials according to the requirements with the 5 types of performances:
for general machining 2300 HV for improving tool life 3000 HV for more speed and feed 3000 HV generally for dry cut 3500 HV for hardened steel and ductile cast iron

Solid Carbide 3 Flute helix end mills CD-16 - 45° and CD-17 - 60°
for stainless steel milling
D1 L1 L2 D2 Code 16 Code 17
3 10 40 3 164503 176003
3.5 10 40 3.5 1645035 1760035
4 12 40 4 164504 176004
4.5 12 50 4.5 1645045 1760045
5 14 50 5 164505 176005
5.5 14 50 5.5 1645055 1760055
6 16 50 6 164506 176006
6.5 16 50 6.5 1645065 1760065
7 16 60 7 164507 176007
7.5 16 60 7.5 1645075 1760075
8 18 60 8 164508 176008
8.5 18 60 8.5 1645085 1760085
9 20 60 9 164509 176009
9.5 20 70 9.5 1645095 1760095
10 22 70 10 164510 176010
D1 L1 L2 D2 Code 16 Code 17
10.5 22 70 10.5 1645105 1760105
11 22 70 11 164511 176011
11.5 22 70 11.5 1645115 1760115
12 25 70 12 164512 176012
13 25 75 13 164513 176013
14 28 75 14 164514 176014
15 28 75 15 164515 176015
16 32 80 16 164516 176016
17 32 80 17 164517 176017
18 32 80 18 164518 176018
19 35 100 19 164519 176019
20 35 100 20 164520 176020

Solid Carbide Multi-Flute Finishing CD-26 - 45° helix
D1 L1 L2 D2 Code 26
4 15 40 4 264504
6 20 50 6 264506
8 25 60 8 264508
10 30 70 10 264510
12 35 75 12 264512
14 35 75 14 264514
16 38 80 16 264516
18 38 80 18 264518
20 40 100 20 264520

Solid Carbide Super Finishing Cutters CD-27 - 50° helix
D1 L1 L2 D2 Z Code 27
6 20 50 6 6 275006
8 25 60 8 8 275008
10 30 70 10 10 275010
12 35 75 12 12 275012
14 35 75 14 14 275014
16 38 80 16 16 275016
18 38 80 18 18 275018
20 40 100 20 20 275020

Solid Carbide Die sinking coned cutter without ball-end CD-30
Coned Ray
D1 L1 L2 D2 Z 0.5° 1° 1.5° 2° 3° 4° 5° 7° 10°
2.5 20 60 4 3 300525 30125 301525 30225
2.5 20 60 6 3 30325 30425 30525
2.5 20 63 8 3 30725
2.5 20 75 10 3 301025
3 20 60 4 3 30053 3012 30153
3 20 60 5 3 3023
3 20 60 6 3 3043
3 25 60 6 3 3033
3 25 60 8 3 3053
3 30 80 14 3 300535 30135 301535 30103
3.5 20 60 5 3 30235
3.5 25 60 8 3 30435
3.5 30 75 8 3 30335
3.5 30 75 10 3 30535
4 20 60 5 3 30054 3014 30154
D1 L1 L2 D2 Z 0.5° 1° 1.5° 2° 3° 4° 5° 7° 10°
4 20 60 6 3 3024
4 30 75 8 3 3034
4 30 75 10 3 3044 3054
5 25 83 12 3 3075
5 30 75 6 3 30055 3015 30155
5 30 75 8 3 3025
5 40 75 10 3 3035
5 40 100 12 3 3045 3055
6 30 75 8 4 30056 3016 30156 3026
6 30 75 10 3 3036
6 30 90 16 3 30106
6 50 100 16 3 3046 3056
8 30 75 10 4 30058 3018 30158 3028
8 30 75 12 4 3038
8 30 100 20 4 30108
D1 L1 L2 D2 Z 0.5° 1° 1.5° 2° 3° 4° 5° 7° 10°
8 50 100 18 4 3048 3058
10 30 75 12 4 300510 30110 301510 30210
10 50 100 16 4 30310
10 50 100 20 4 30410 30510
12 50 100 14 4 300512 30112
12 50 100 16 4 301512 30212
12 50 100 20 4 30512
12 55 100 18 4 30312
12 20 4 30412
16 60 100 18 4 300516 30116
16 60 100 20 4 301516

Solid Carbide Die sinking coned cutter with ball-end CD-R30
Coned Ray
D1 L1 L2 D2 Z 0.5° 1° 1.5° 2° 3° 4° 5° 7° 10°
2.5 20 60 4 3 R300525 R30125 R301525 R30225
2.5 20 60 6 3 R30325 R30425 R30525
2.5 20 63 8 3 R30725
2.5 20 72 10 3 R301025
3 20 60 4 3 R30053 R3012 R30153
3 20 60 5 3 R3023
3 20 60 6 3 R3043
3 25 60 6 3 R3033
3 25 60 8 3 R3053
3 30 83 14 3 R300535 R30135 R301535 R30103
3.5 20 60 5 3 R30235
3.5 25 60 8 3 R30435
3.5 30 75 8 3 R30335
3.5 30 75 10 3 R30535
4 20 60 5 3 R30054 R3014 R30154
D1 L1 L2 D2 Z 0.5° 1° 1.5° 2° 3° 4° 5° 7° 10°
4 20 60 6 3 R3024
4 30 75 8 3 R3034
4 30 75 10 3 R3044 R3054
5 25 83 12 3 R3075
5 30 75 6 3 R30055 R3015 R30155
5 30 75 8 3 R3025
5 40 75 10 3 R3035
5 40 100 12 3 R3045 R3055
6 30 75 8 4 R30056 R3016 R30156 R3026
6 30 75 10 3 R3036
6 30 92 16 3 R30106
6 50 100 16 3 R3046 R3056
8 30 75 10 4 R30058 R3018 R30158 R3028
8 30 75 12 4 R3038
8 30 104 20 4 R30108
8 50 100 18 4 R3048 R3058
D1 L1 L2 D2 Z 0.5° 1° 1.5° 2° 3° 4° 5° 7° 10°
10 30 75 12 4 R300510 R30110 R301510 R30210
10 50 100 16 4 R30310
10 50 100 20 4 R30410 R30510
12 50 100 14 4 R300512 R30112
12 50 100 16 4 R301512 R30212
12 50 100 20 4 R30512
12 55 100 18 4 R30312
12 20 4 R30412
16 60 100 18 4 R300516 R30116
16 60 100 20 4 R301516

In order having any difficulties and failure using the solid carbide on machining application, it should be checked on Trouble Shooting Guidelines.
  • All the dimensions can be changed without prior notice.
  • Other specification and dimension, on request.
